Non-rotation Wire Rope

We supply a large range of non-rotating wire ropes in both galvanized and ungalvanized finish with either ordinary or lang lay. Depending upon your requirement for higher breaking load or better wear characteristics, these wire ropes are available in different finishes and lubrications as well as being available with plastic impregnated.

Classification:

Wire Rope

Related Products

Product Consulting

Product Details

For various equipment of lifting,hoisting and dragging, the rope with steel core may be used under the shock load、heated and squeezed condition.

Specifications of Non-rotating wire rope:
• Constructure: 19x7
• Size: 6--50mm
• Surface treatment: Hot dip galvanized, electric galvanized, ungalvanized,
• Tensile strength: 1570MPA, 1670MPA, 1770MPA, 1870MPA, 1960MPA
• Standard: As per GB,JIS, RR-W,API and etc ,as well as customer`s request
• Application: Crane, Hoist and General Engineering Purposes
• Characteristic: Good wear resistance and longer fatigue life
• Packing type: Wooden reel
Remarks during use and handling:
During transportation, handle softy and carefully, avoid bumping and damaging the outer packing materials.
Moisture and rain prohibited. Steel wire ropes must be stored in dry and well ventilated indoors.
Pay attention to direction of pay-off and take-up to avoid importing additional stress.
At work site, pay attention to the threading direction and avoid additional stress and curving of the wire ropes.

Diameter (mm)	（kg/100m) Approx Weight		Min Breaking Strength
			1570		1670		1770		1870		1960		2160
			Minimum Breaking Load（KN)
	FC	IWR IWS	FC	IWR IWS	FC	IWR IWS	FC	IWR IWS	FC	IWR IWS	FC	IWR IWS	FC	IWR IWS
6	14.0	15.5	17.5	18.5	18.6	19.7	19.8	20.9	20.9	22.1	21.9	23.1	24.1	25.5
7	19.1	21.1	23.8	25.2	25.4	26.8	26.9	28.4	28.4	30.1	29.8	31.5	32.8	34.7
8	25.0	27.5	31.1	33.0	33.1	35.1	35.1	37.2	37.1	39.3	38.9	41.1	42.9	45.3
9	31.60	34.8	39.4	41.7	41.9	44.4	44.4	47.0	47.0	49.7	49.2	52.1	54.2	57.4
10	39.0	43.0	48.7	51.5	51.8	54.8	54.8	58.1	58.0	61.3	60.8	64.3	67.0	70.8
11	47.20	52.0	58.9	62.3	62.6	66.3	66.3	70.2	70.1	74.2	73.5	77.8	81.0	85.7
12	56.20	61.9	70.1	74.2	74.5	78.9	78.9	83.6	83.6	88.3	87.5	92.6	96.4	102
13	65.90	72.7	82.3	87.0	87.5	92.6	92.6	98.1	98.1	104	103	109	113	120
14	76.40	84.3	95.4	101	101	107	107	114	114	120	119	126	131	139
16	99.80	110	125	132	133	140	140	149	149	157	156	165	171	181
18	126	139	158	167	168	177	177	188	188	199	197	208	217	230
20	156	172	195	206	207	219	219	232	232	245	243	257	268	283
22	189	208	236	249	251	265	265	281	281	297	294	311	324	343
24	225	248	280	297	298	316	316	334	334	353	350	370	386	408
26	264	291	329	348	350	370	370	392	392	415	411	435	453	479
28	306	337	382	404	406	429	429	455	454	481	476	504	525	555
30	351	387	438	463	466	493	493	523	522	552	547	579	603	638
32	399	440	498	527	530	561	561	594	594	628	622	658	686	725
34	451	497	563	595	598	633	633	671	671	709	702	743	774	819
36	505	557	631	667	671	710	710	752	751	795	787	833	868	918
38	563	621	703	744	748	791	791	838	837	886	877	928	967	1020
40	624	688	779	824	828	876	876	929	928	981	972	1030	1070	1130
42	688	759	859	908	913	966	966	1020	1020	1080	1070	1130	1180	1250
44	755	832	942	997	1000	1060	1060	1120	1120	1190	1180	1240	1300	1370
